VibraForge: A Scalable Prototyping Toolkit For Creating Spatialized Vibrotactile Feedback Systems

PubDate: Sep 2024

Teams:University of Toronto

Writers:Bingjian Huang, Siyi Ren, Yuewen Luo, Qilong Cheng, Hanfeng Cai, Yeqi Sang, Mauricio Sousa, Paul H. Dietz, Daniel Wigdor

PDF:VibraForge: A Scalable Prototyping Toolkit For Creating Spatialized Vibrotactile Feedback Systems

Abstract

Spatialized vibrotactile feedback systems deliver tactile information by placing multiple vibrotactile actuators on the body. As increasing numbers of actuators are required to adequately convey information in complicated applications, haptic designers find it difficult to create such systems due to limited scalability of existing toolkits. We propose VibraForge, an open-source vibrotactile toolkit that supports up to 128 vibrotactile actuators. Each actuator is encapsulated within a self-contained vibration unit and driven by its own microcontroller. By leveraging a chain-connection method, each unit receives independent vibration commands from a control unit, with fine-grained control over intensity and frequency. We also designed a GUI Editor to expedite the authoring of spatial vibrotactile patterns. Technical evaluations show that vibration units reliably reproduce audio waveforms with low-latency and high-bandwidth data communication. Case studies of phonemic tactile display, virtual reality fitness training, and drone teleoperation demonstrate the potential usage of VibraForge within different domains.
